Emilio Stainless is a reputable manufacturer and supplier located in Manila, Philippines, known for its top-notch Stainless Steel Sockets. With a strong focus on precision engineering and durability, the company provides a wide array of socket fittings that deliver exceptional performance across various industrial systems. Emilio Stainless guarantees that every product adheres to international standards for strength, corrosion resistance, and reliability. Their stainless steel sockets are celebrated for their seamless integration, leak-proof connections, and impressive longevity, making them perfect for piping, plumbing, and mechanical systems in a variety of sectors.
Stainless Steel Sockets are generally made from a blend of iron, chromium, nickel, and molybdenum, which gives them remarkable corrosion resistance and durability. Common grades like 304, 304L, 316, and 316L are favored for their excellent weldability and toughness. These sockets boast outstanding mechanical properties, including high tensile strength, good ductility, and resistance to pitting and oxidation. They perform reliably even in high-pressure and high-temperature environments, ensuring safe and efficient operation in numerous industrial applications.
| Grades | 201, 202, 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L |
| Type | Seamless / Welded / Fabricated |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Size | ½”NB to 48″NB in |
| Schedule | Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| SS | 304 | 304N | 304LN |
|---|---|---|---|
| Ni | 8 – 11 | 8 – 11 | 8 – 11 |
| Fe | Balance | ||
| Cr | 18 – 20 | 18 – 20 | 18 – 20 |
| C | 0.08 max | 0.08 max | 0.035 max |
| Si | 0.75 max | 0.75 max | 0.75 max |
| Mn | 2 max | 2 max | 2 max |
| P | 0.040 max | 0.040 max | 0.040 max |
| S | 0.030 max | 0.030 max | 0.030 max |
| N | 0.10 – 0.16 | 0.10 – 0.16 | |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Contact us to get a quick quote for your requirement.
Our stainless steel sockets are manufactured to the highest quality. Each piece is thoroughly tested in terms of hardness, chemical analysis, PMI testing, flattening, as well as micro and macro test, pitting resistance, flaring, and IGC tests. We give documentation that includes commercial invoice, packing lists, Certificated of Origin, and a letter of guarantee for everything that’s put under transparency. To spice things, we have third-party inspection certificates that affirm the customer’s satisfaction and product quality.
Stainless steel sockets are highly resistant to corrosion due to their chromium content, but they may corrode under extreme conditions, such as exposure to harsh chemicals or seawater. Regular maintenance ensures longevity.
Stainless steel sockets can attract magnets if they are made from ferritic or martensitic stainless steel, which contain magnetic properties. However, austenitic stainless steel, commonly used, is non-magnetic.
Yes, stainless steel sockets can be recycled after use. Stainless steel is a highly recyclable material, and recycling it helps reduce environmental impact while conserving valuable resources.
Yes, stainless steel sockets can be used for underground applications. Their corrosion resistance makes them suitable for harsh environments, ensuring durability and performance in buried or underground installations.
You’ll find Stainless Steel Sockets in industries such as oil and gas, chemical processing, power generation, food processing, and water treatment. They’re perfect for connecting pipes in systems that demand high-pressure resistance and corrosion protection. These sockets create strong, leak-free joints and are suitable for both seamless and welded piping systems. Common uses include hydraulic lines, steam systems, and fluid transfer networks. Thanks to their strength, precision, and reliability, stainless steel sockets are vital components in today’s industrial infrastructure.
