Emilio Stainless is a reputable manufacturer and supplier located in Manila, Philippines, with a focus on high-quality Stainless Steel Rectangle Pipes. The company prides itself on precision engineering and durability, offering a diverse selection of stainless steel rectangular pipes that cater to various structural and industrial needs. Each product is crafted to meet international standards, guaranteeing exceptional strength, corrosion resistance, and visual appeal. Emilio Stainless serves a wide array of sectors, including construction, automotive, and fabrication, delivering dependable solutions that blend functionality with long-lasting performance for both domestic and commercial projects throughout the Philippines and beyond.
Stainless Steel Rectangle Pipes are primarily made up of iron, chromium (18–20%), and nickel (8–10.5%), along with trace amounts of carbon, manganese, and silicon. This unique blend ensures outstanding corrosion resistance and strength. Mechanically, these pipes showcase high tensile strength, durability, and resistance to oxidation and scaling, even at elevated temperatures. They are also recognized for their toughness and ease of fabrication, making them perfect for both structural and decorative applications in challenging environments.
| Size | 10 X 20, 12.75 X 25.4, 10 X 30, 15 X 30, 20 X 40, 20 x 50, 25 X 50, 20 x 60, 40 X 60, 40 X 80, 45 X 75, 50 X 100 |
|---|---|
| Grades | TP – 304, 304L, 316, 316L, 201 |
| Standards | A312 – A358 – A409 – A554 – A778 – A789 – A790 |
| Tolerance on Length | Commercial Length: 6000 milimeter +/- 30 milimeter Fix Length: from 1200 milimeter up to 12000 milimeter with a tolerance up to -0/+ 5mm |
| Finish | Polished Grit 120 – 600, Seamless, Welded, Brushed, Pickled, Solution Annealed and Pickled up to O.D. 219.1 milimeter,Mirror Polished |
| PIPE GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ||||
| TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | ||||
| TP316 | S3160 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
| TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
|---|---|---|---|---|---|
| Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| º F(º C) | |||||
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
Contact us to get a quick quote for your requirement.
The company also conducts various tests to ensure the pipes are of high standard before being shipped out. Some of the tests include Hardness Test, Chemical Analysis via Spectro Analysis, Positive Material Identification (PMI)-Testing, Flattening Test, Micro & Macro Test, Pitting Resistance Test, Flaring Test, and Intergranular Corrosion (IGC)-Test among others. In addition, the documentation is very complete for full traceability and observance of industrial standards.
Yes, stainless steel rectangle pipes can be welded using appropriate welding techniques such as TIG or MIG welding. Proper preparation and filler material are essential for strong, durable welds.
Stainless steel rectangle pipes are highly resistant to corrosion due to their chromium content. However, they may corrode in harsh environments with high chloride exposure or inadequate maintenance.
Yes, stainless steel rectangle pipes can be used for natural gas applications due to their strength, corrosion resistance, and ability to withstand high pressure, ensuring safe and durable performance.
Stainless steel rectangle pipes made from austenitic grades (like 304 and 316) are generally non-magnetic. However, some ferritic or martensitic grades may exhibit magnetic properties.
These Stainless Steel Rectangle Pipes find extensive use in architectural structures, frames, supports, and handrails, thanks to their strength and sleek appearance. In the industrial realm, they are essential for equipment fabrication, machinery frameworks, and chemical processing plants due to their corrosion-resistant qualities. The construction industry relies on them for building infrastructure and design elements, while the automotive and marine sectors utilize them for exhaust systems and fluid transfer. Their versatility, durability, and polished finish make them an excellent choice for applications that demand both mechanical performance and aesthetic appeal.
