Emilio Stainless, located in Manila, Philippines, stands out as a top-notch manufacturer and supplier of high-quality stainless steel products, including Stainless Steel Tees. Known for their precision engineering and robust construction, Emilio Stainless guarantees that each Tee adheres to international standards for performance and reliability. They serve a wide array of industries, from plumbing and chemical to food processing, offering products that boast exceptional corrosion resistance and longevity. With a strong commitment to excellence, timely delivery, and competitive pricing, Emilio Stainless has become a trusted partner for businesses looking for reliable stainless steel fittings in the Philippines and beyond.
Stainless Steel Tees are generally made from grades like 304, 316, or 321 stainless steel, which provide outstanding resistance to corrosion and oxidation. They feature high tensile strength, durability, and thermal resistance, making them perfect for both high-pressure and high-temperature applications. Thanks to their superior weldability and formability, these tees can be seamlessly integrated into complex piping systems. Their mechanical properties include impressive hardness, ductility, and impact resistance, ensuring dependable performance over a long service life, even in challenging environments.
| Grades | 201, 202, 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L |
| Type | Seamless / Welded / Fabricated |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Size | ½”NB to 48″NB in |
| Schedule | Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| SS | 304 | 304N | 304LN |
|---|---|---|---|
| Ni | 8 – 11 | 8 – 11 | 8 – 11 |
| Fe | Balance | ||
| Cr | 18 – 20 | 18 – 20 | 18 – 20 |
| C | 0.08 max | 0.08 max | 0.035 max |
| Si | 0.75 max | 0.75 max | 0.75 max |
| Mn | 2 max | 2 max | 2 max |
| P | 0.040 max | 0.040 max | 0.040 max |
| S | 0.030 max | 0.030 max | 0.030 max |
| N | 0.10 – 0.16 | 0.10 – 0.16 | |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Contact us to get a quick quote for your requirement.
We ensure that every Stainless Steel Tee Fitting undergoes rigorous testing before leaving our premises, maintaining the highest quality standards at all times. Hardness Testing, Chemical Analysis (Spectro Analysis), Positive Material Identification (PMI Testing), Flattening Test, Micro and Macro Testing, Pitting Resistance Test, Flaring Test and Intergranular Corrosion (IGC) Testing are just some of the tests performed on Stainless Steel Tee Fittings before shipping.
Yes, stainless steel tees are fully recyclable. They can be melted down and reused without losing their properties, making them an environmentally friendly and sustainable material choice.
Common grades of stainless steel used in tee fittings manufacturing include 304, 304L, 316, 316L, and 321. These grades offer excellent corrosion resistance, durability, and suitability for various applications.
Yes, stainless steel tee fittings are ideal for hygienic and sanitary applications due to their corrosion resistance, smooth surfaces, and ease of cleaning, meeting strict industry standards.
Key considerations for selecting stainless steel tee fittings include material grade, corrosion resistance, pressure and temperature requirements, compatibility with media, application standards, and cost-effectiveness for long-term use.
These Stainless Steel Tees find extensive use in industries such as chemical processing, oil and gas, pharmaceuticals, and food and beverage. They enable the branching of pipelines, allowing for efficient fluid distribution and changes in flow direction. Common applications include water treatment systems, sanitary piping, and industrial fluid handling systems. Their corrosion resistance makes them ideal for managing aggressive chemicals, while their strength guarantees leak-free operation under high pressure. Additionally, they are utilized in HVAC systems, marine applications, and construction projects, providing durable, low-maintenance solutions that enhance overall system reliability and safety.
