Emilio Stainless, located in Manila, Philippines, stands out as a top manufacturer and supplier of high-quality Stainless Steel 304/304L Angles. Renowned for their precision engineering and strict quality control, these angles are designed to meet international standards, offering exceptional corrosion resistance, durability, and mechanical strength. The SS 304/304L Angles are austenitic stainless steel products that excel in industrial, structural, and architectural applications where long-lasting reliability is essential. With cutting-edge manufacturing techniques and thorough quality checks, Emilio Stainless guarantees that each angle meets rigorous performance standards, providing consistent quality and high-performance solutions for clients both in the Philippines and abroad.
Stainless Steel 304/304L Angles are primarily made of iron, featuring 18–20% chromium, 8–10.5% nickel, and ≤0.08% carbon for the 304L grade, along with small amounts of manganese, silicon, and phosphorus. This type of austenitic stainless steel boasts a tensile strength ranging from 515 to 720 MPa and a yield strength of about 205 to 250 MPa, along with impressive ductility and toughness. These angles deliver remarkable corrosion resistance, dimensional stability, and mechanical integrity across various environments, including mildly corrosive and industrial settings. They retain their structural strength and performance even during fabrication processes like cutting, bending, and welding.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
At Emilio Stainless, all stainless steel 304/304L faces are rigorously tested to ensure quality and reliability. Certified to international standards, our products come with material test reports (MTR), third-party inspection certificates, and compliance with ASTM/ASME specifications. This ensures optimal performance, security and customer reliability in any application.
Stainless Steel 304/304L angles are L-shaped structural sections offering high strength, corrosion resistance, and durability. They are used in construction, manufacturing, and architectural applications for support and reinforcement.
Stainless Steel 304/304L equal angles feature two legs of the same length, forming a 90-degree angle. They provide strong, durable support and are widely used in construction and structural applications.
Stainless Steel 304/304L unequal angles have legs of different lengths, forming a 90-degree angle. They offer versatile support and reinforcement in construction and industrial applications, with high strength and corrosion resistance.
Stainless Steel 304/304L L angles are L-shaped structural components used for framing and support. They provide high strength, durability, and corrosion resistance, suitable for construction, manufacturing, and architectural applications.
SS 304/304L T-bar angles are stainless steel sections with a T-shaped profile. They provide robust support and stability for structural and framework applications, offering high strength, durability, and corrosion resistance.
Stainless Steel 304/304L corner angles are L-shaped sections designed to reinforce and join corners. They offer high strength, durability, and corrosion resistance, ideal for construction and architectural applications.
Stainless Steel 304/304L Angles find extensive use in industries that demand corrosion-resistant, durable, and robust structural components. They are perfect for construction frameworks, machinery supports, industrial equipment, pipelines, and architectural projects. In commercial applications, you’ll see them used for furniture, handrails, brackets, and decorative elements. Their excellent corrosion resistance and weldability make them ideal for both functional and aesthetic purposes. Emilio Stainless provides 304/304L Angles to meet the diverse needs of their clients.
