Emilio Stainless is a top-notch manufacturer and supplier located in Manila, Philippines, specializing in high-quality Stainless Steel 316/316L Angles. These angles are well-known for their remarkable strength, resistance to corrosion, and versatility. With a commitment to precision and adherence to international standards, Emilio Stainless guarantees that each product offers long-lasting performance, even in tough environments. Stainless Steel 316/316L Angles are perfect for both structural and industrial applications, making them a go-to choice in construction, marine, chemical, and food processing industries where durability and reliability are crucial.
Stainless Steel 316/316L Angles are made up of 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, which enhance their resistance to corrosion and pitting, particularly in chloride-rich settings. The 316L grade has a lower carbon content, which helps reduce carbide precipitation and improves weldability. These angles boast a tensile strength of around 515 MPa, a yield strength of 205 MPa, along with good elongation and hardness. Their exceptional mechanical and thermal stability makes them ideal for high-pressure and high-temperature applications while still maintaining excellent formability and toughness.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
We conducts a strict quality test and obtains certifications to guarantee the best Stainless Steel 316/316L Angles in terms of strength, corrosion resistance, and accuracy. Each product batch is certified for compliance with international standards and offers clients full assurance in terms of reliability, performance, and conformity to industrial needs for a variety of uses.
Stainless Steel 316/316L angles are L-shaped structural components known for their excellent corrosion resistance, strength, and durability. They are used in marine, chemical, and high-temperature applications for support and reinforcement.
Stainless Steel 316/316L equal angles have two legs of the same length, forming a 90-degree angle. They offer high strength and corrosion resistance, ideal for structural support in demanding environments.
Stainless Steel 316/316L unequal angles have legs of different lengths, creating a 90-degree angle. They provide versatile support and reinforcement in construction and industrial applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L L angles are L-shaped structural components offering high strength, durability, and superior corrosion resistance. They are used for framing and support in marine, chemical, and high-temperature environments.
SS 316/316L T-bar angles are stainless steel sections with a T-shaped profile, providing robust support and stability. They are ideal for structural and framework applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L corner angles are L-shaped sections designed for reinforcing and joining corners. They offer high strength, durability, and excellent corrosion resistance, making them suitable for construction and architectural applications.
Stainless Steel 316/316L Angles find extensive use in structural frameworks, supports, and reinforcements for buildings, bridges, and machinery. They are also favored in marine environments, offshore platforms, and chemical plants due to their impressive resistance to seawater and corrosive substances. In the food and pharmaceutical sectors, these angles are utilized in the construction of equipment and storage systems that require high standards of hygiene and cleanliness. Furthermore, they are employed in fabrication projects, architectural designs, and industrial machinery where strength, corrosion resistance, and a polished finish are essential.
